CIMC Brand New 3 Axle Refrigerated Semi Trailer For Sale

Overview

Overview

CIMC Brand New 3 Axle Refrigerated Semi Trailer For Sale

Product Description

45ft 13.6M Thermo King Refrigeration unit Refrigerator Semi Trailer .jpg

DOT 13.6M Carrier LONG MULTI-TEMP REFRIGERATED REEFER semi trailer.png

CIMC Brand New 3 Axle Refrigerated Semi Trailer For Sale

Technical Parameter of 3 Axles 45ft Refrigerator Semi Trailer
Overall Dimension	13600mmx2600mmx4000mm( Exact size depends on the final design)
Refrigerator box dimensions	13435x2470x2450mm
Loading capacity	80cbm
GVW	Approx :40000KGS
Tare weight kg	Approx: 10400KGS
Refrigerator box material	Inside and external FRP, left and right side plate 10 cm thick, roof 10 cm thick, bottom plate 10 cm thick, the internal top of the box is equipped with ventilation cloth,bottom vent. The bottom plate paved U-type aluminum track rail, rear horseshoe welding, large edge.
Refrigerator unit	Thermo King brand MP4000,Independent refrigeration unit
Door	Side with two doors. Rear is double doors, the new model is 5 sealing ring, inside and outside with aluminum alloy pressure strip, sealing effect is better, no air leakage!
Special request from buyer	Add the temperature and humidity recorder, then can print the driver's record during the trip .
Axles	3pcs 13TONS FUWA axles
Tire	12.00R20 or 12.00R22.5
Landing Gear	China brand 28T(two speed)
Brake System	WABCO Valve with big chamber
King Pin	JOST bolt-in king pin
Suspension	Mechanical suspension (Optional Air suspension)
Leaf Spring	90(W)mm×13(Thickness)mm×10(Layer) or 100mm×12mm×12
Rear ladder	Dismountable
Lights	Turning Light, Side Marker Light, Tail Light
Voltage	24V
Receptacle	7 ways (7 wire harness)
Others	Two spare tire frame, iron guardrail, iron bumper, iron tool box.
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
ABS	Optional
Accessories	Factory standard
Color /Logo	As the request of buyer
